Technical Data
Speaker Type: 2-Way Active Speaker
Acoustical data
Frequency Response [-10dB]: 46 - 20.000 Hz
Max SPL: 133 dB
HF: 1.4 "
Type HF: Titanium Compression driver
Voice Coil HF: 2.8"
Directivity: 60 x 40 °
Horn: CD Horn
Rotatable Horn: YES
LF: 15"
Voice Coil LF: 3"
Amplifier
Amp Technology: Digipro® G2
Amp Class: Class D
Power PRG: 1000 W
Peak Power: 2000 W
Processor
Controller: DSP 24bit/48kHz
System Presets: Flat, Boost
Limiter: Dual Active Peak, RMS, Thermal
Crossover Frequency MF-HF: 1100 Hz
Slope MF-HF: 24 dB/Octave
Input
Mechanics
Housing: Multiplex with H.E.T coating, reinforced
Width: 509 mm (20.36 in)
Height: 765 mm (30.6 in)
Depth: 533 mm (21.32 in)
Weight: 33 kg (72.75 lbs)
